Odin 2 Tonearm Cable

ODIN 2 TONEARM CABLE +

Nordost’s Odin 2 Tonearm Cable + is the perfect solution for audiophiles who want the absolute best from their high-resolution, vinyl-sourced systems. Nordost’s Odin 2 Tonearm Cable + consists of four, silver-plated, solid core 99.999999% OFC conductors, wrapped in a patented Dual Mono-Filament suspension. This innovative and proprietary design element dramatically increases signal speed and reduces insulation contact by 85%. The conductors are individually shielded using Nordost’s unique Total Signal Control (TSC) technology, allowing for 100% coverage and protection from external pollution (such as RFI and EFI) and crosstalk.

In order to combat noise, Nordost’s O2 Tonearm Cable + takes a two-prong approach. Firstly, Nordost’s Supreme Reference tonearm cable runs a fully isolated bond ground throughout the cable, which connects the chassis of the turntable and phono-stage, creating a secure, low noise connection between the two components. The second method is a versatile solution, ensuring that Nordost’s tonearm cable will be able to address any grounding need, regardless of the unique construction of the components in the sound system. Each Odin 2 Tonearm Cable + will include two, detachable, silver-plated ground whips, complete with Dual Mono-Filament technology and TSC shielding. When needed, these ground whips connect to the shielding of the tonearm cable, totally eliminating any noise that could be introduced during signal transfer.

The Odin 2 Tonearm Cable + is measured to precise mechanically tuned lengths and is terminated with Nordost’s proprietary HOLO:PLUG® Straight or 90º low-mass 5-pin Din, RCA, or XLR connectors, which have been specifically designed to accommodate the cable’s unique design. Nordost’s Supreme Reference-level tonearm cable eliminates noise and provides the low levels of capacitance needed to maintain the integrity of such fragile signals, ensuring a truly sublime vinyl listening experience.


SPECIFICATIONS

Insulation:
High purity extruded Fluorinated Ethylene Propylene (FEP)
Construction:
Mechanically tuned lay, length and Dual Mono-Filament, TSC design
Conductors:
4 x 23 AWG
Material:
Silver plated 99.999999% OFC Solid Core
Capacitance:
RCA: 9.75pF/ft | XLR: 23.5pF/ft
Inductance:
RCA: 0.11μH/ft | XLR: 0.06μH/ft
Overall Shield Coverage:
100% Individually shielded
Bond / Grounding Whips:
23 AWG silver-plated, Solid Core OFC, Dual Mono-Filament design.
Velocity of Propagation:
90%
Termination:

HOLO:PLUG® gold-plated Straight or 90० low-mass 5-pin Din, RCA, or XLR connectors. Whips and bond wire terminated with gold-plated 5mm spades.
AVAILABLE CONNECTORS

Odin 2 Tonearm Cable Connectors

MORE INFO

ODIN 2 TONEARM CABLE + INSTRUCTION MANUAL

Connecting, grounding, and determining the optimal configuration for additional shield grounding.

NORDOST ODIN 2 TONEARM CABLE +

"This is the best damn cable to hook a turntable to a phono stage. Ever."

– Alan Sircom, Hi-Fi+

Tonearm Cable + Instruction Manual

COMPLETE TURNTABLE SET-UP GUIDE

A correctly set-up turntable, tonearm, and cartridge can make a world of difference when you sit down to enjoy your favorite vinyl. With this in mind, Nordost has put together a series of helpful hints to properly set-up your own turntable. This Complete Turntable Set-Up Guide will help you achieve the best possible sound from your analog-driven system in no time.
